Thevenin's Theorem

Thevenin's Theorem states that any linear, bilateral two-terminal network can be replaced by an equivalent circuit consisting of:
A Thevenin voltage (VTH)
A Thevenin resistance (RTH)
A series connection with the load.
Use Ohm's Law to calculate the load current: I = Vth/(Rth + Rl)
Thevenin Voltage: Vth = Voc
